Announcements

Pset 9 problem 3: we mean CONNECTED manifolds for the 3 chart result. A fancy way to say this is that the Lusternik Schnirelmann category of a CONNECTED 2-manifold is maximally 3. See this blog entry from 2022 featuring also pictures from the Harvard-Yale game 2022, just after a grad school friend of mine died, with whom I had worked on discrete Lusternik-Schnirelmann stuff in 2012, updated in 2024. Here is the code for Pset 9:
Generate[A_]:=If[A=={},{},Sort[Delete[Union[Sort[Flatten[Map[Subsets,A],1]]],1]]];
Whitney[s_]:=Generate[FindClique[s,Infinity,All]]; w[x_]:=-(-1)^k;
R[G_,k_]:=Module[{},R[x_]:=x->RandomChoice[Range[k]]; Map[R,Union[Flatten[G]]]];
F[G_]:=Delete[BinCounts[Map[Length,G]],1]; Euler[G_]:=F[G].Table[w[k],{k,Length[F[G]]}];
Surface[G_,g_]:=Select[G,SubsetQ[#/.g,Union[Flatten[G] /. g]] &];
S[s_,v_]:=VertexDelete[NeighborhoodGraph[s,v],v];     Sf[s_,v_]:=F[Whitney[S[s,v]]];
Curvature[s_,v_]:=Module[{f=Sf[s,v]},1+f.Table[(-1)^k/(k+1),{k,Length[f]}]];
Curvatures[s_]:=Module[{V=VertexList[s]},Table[Curvature[s,V[[k]]],{k,Length[V]}]];
J[G_,H_]:=Union[G,H+Max[G]+1,Map[Flatten,Map[Union,Flatten[Tuples[{G,H+Max[G]+1}],0]]]];
ToGraph[G_]:=UndirectedGraph[n=Length[G];Graph[Range[n],
  Select[Flatten[Table[k->l,{k,n},{l,k+1,n}],1],(SubsetQ[G[[#[[2]]]],G[[#[[1]]]]])&]]];
Barycentric[s_]:=ToGraph[Whitney[s]];

G=J[Whitney[Barycentric[CompleteGraph[{2,2,2}]]],Whitney[CycleGraph[7]]];  (* J=Join *)
g=R[G,3]; H=Surface[G,g];   (* A codimension 2 manifold in the 4-sphere G=Oct * C_7  *)
Print["EulerChi= ",Euler[H]]; Print["Fvector: ",F[H]];s=ToGraph[H];GraphPlot3D[s]
Print["Gauss-Bonnet Check: "]; Print[Total[Curvatures[s]]==Euler[H]];
Print["Curvature Values:  "];  Print[Union[Curvatures[s]]];
One of the theorems (discovered 2015 and upgraded 2024) covered today is featured in some shorts. It is part of finite differential topology or differential geometry. We will also see the general Gauss-Bonnet theorem, which holds for all networks. The first short is presented in the language of graphs, the second short from last summer uses the language of finite abstract simplicial complexes.

Lecture notes

Homework

Exams

W1    1 Wednesday September 2:      Surfaces and curves

W2
      2 Monday   September 7:       Labor day, no class
      3 Wednesday September 9:      Relevant linear algebra and analysis
W3
      4 Wednesday  September 14:    Frenet theorem in two and 3 dimensions
      4 Wednesday  September 16:    Frenet theorem in arbitrary dimensions

W4    6 Monday   September 21:      Hopf Umlaufsatz
      7 Wednesday  September 23:    Four vertex theorem

W5    8 Monday   September 28:      The fundamental forms I,II,III
      9 Wednesday  September 30:    The Gauss Map A and Curvature K

W6   10 Monday  October 5:          Discrete differential geometry
     11 Wednesday October 7:        Review for midterm

W7   12 Monday  October 12:         Columbus day, no classes
     13 Wednesday October 14:       In-class part Midterm

W8   14 Monday  October 19:         Calculus of variations and Geodesics
     15 Wednesday October 21:       Exponential map and geodesic coordinates

W9   16 Monday  October 26:         Differential forms and Green's Theorem
     17 Wednesday October 28:       The Theorema Egregium

W10  18 Monday  November 2:         Local Gauss Bonnet theorem
     19 Wednesday November 4:       Global Gauss Bonnet theorem

W11  20 Monday  November 9:         Riemannian manifolds
     21 Wednesday November 11:      Discrete manifolds

W12  22 Monday  November 16:        Curvature and Ricci tensors
     23 Wednesday November  18:     General relativity

W13  24 Monday  November 23:        Discrete general relativity
        November 25- November 29:   Thanksgiving

W14  25 Monday  December 2:         Final review
     26 Wednesday December 4:       In class part final
  • Lecture notes consist of "units". Lectures and units do not correspond in general. The first 2 lectures cover 4 units and cover mostly material you know from calculus and linear algebra. We build on this!
  • Grades: HW 40 percent, midterm 30 (in-class/take-home combined), final 30 (in-class/paper combined)
